TMax 100
Pallet truck for handling of very heavy loads in narrow spaces
TMax 100, with load capacity up to 10000 kg, is the ideal pallet truck for those working with very heavy loads in narrow spaces. The central electric steering system, tiller arm and traction group allow excellent driving ergonomics, safety and great truck manoeuvrability.
STRENGTHS:
- Alternating Current traction electronics and steering system with CAN BUS technology
- Powerful 4000 W traction motor
- 375 Ah side removal battery (up to a maximum of 500 Ah)
- High frequency battery charger
- Very robust frame and fork group, with 130 mm fork lifting height
- Fork dimensions suitable to handle Euro pallets up to a load capacity of 8000 kg, for greater load capacities the forks will have a different dimensioning
✔ LOAD CAPACITY UP TO 10.000 KG
✔ CUSTOMISABLE ACCORDING TO THE CUSTOMER’S NEEDS
✔ SPECIAL DIMENSIONS UPON REQUEST
- some optionals
- Operator transport platform
- Metallic/galvanised version
- Lithium battery
- Scale/Printer
- Use in cold store
| Type | Power pallet trucks | Class | Power pallet trucks for intensive use and heavy loads |
|---|---|---|---|
| Load capacity (Kg) | 10000 | Lifting capacity (mm) | 130 |
